Model T-2350

$35,351.00

SKU: model-t-2350 Category: Tags: , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , Brand:

Description

Model T-2350
350 Nominal Tons based on design of 95/85/75 @ 1,036 GPM
Fan Motor 10 HP, 208-230/460V, 3PH, 60Hz
*Electrical hookups are inside the junction box located on fan motor
Speed Reducer VBA-075-B
Cooling Capacity 5,250,000 BTU/hr
Air Volume 77,020 CFM
Water Inlet 8″
Water Outlet 8″
Tower Diameter 188 5/8″
Tower Height
 133 1/2″
Operating Weight 9,962 lbs.
Dry Weight 3,002 lbs.
Flange Type Round, 150# Cast Iron


Please note:  If you would like a formal quote, please contact our sales office.

Additional information

Weight 10000.0 lbs
hidden

0
Motor Specifications

208V/230V/460V, 3PH, 60Hz
