Model T-3500

$142,674.00

SKU: model-t-3500 Category: Tags: , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , Brand:

Description

Engineering Information

Model T-3500
1,500 Nominal Tons based on design of 95/85/75 @ 4,516 GPM
Fan Motor 50 HP, 208-230/460V, 3PH, 60Hz
*Electrical hookups are inside the junction box located on fan motor
Speed Reducer VBA-375
Cooling Capacity 22,500,000 BTU/hr
Flange Type Round, 150# Cast Iron
Operating Weight 57,789 lbs.
Dry Weight 15,432 lbs.


Please note: If you would like a formal quote, please contact our sales office.

Additional information

Weight 10000.0 lbs
hidden

0
Motor Specifications

208/230/460V, 3, 60 Hz
